Description

– Both AC and DC output (DC regulated)
– DC continuously adjustable and AC step-by-step
– LED meters for both voltage and current display
– Over heat protection for the device
– Current-limit protection for DC output
– Short-circuit protection for AC output
Specifications:
DC Output:
Output Voltage: 0~15V
Output Current: 7A
Load Regulation: 5mV
Line Regulation: 2mV
Ripple: 2mV
AC Output:
Output Voltage: 1.5V, 3V, 4.5V, 6V, 7.5V, 9V, 12V,
15V
Output Current: 7A
Input Voltage: 220~240VAC ±10%
Dimensions: 175(W)×180(H)×270(D)mm
Weight: 5kg
