Specification
Digital Camera System
1.3M pixels, 1/2” CMOS, 1280×1024, USB 2.0, 15～30 fps
2.0M pixels, 1/2” CMOS, 1600×1200, USB 2.0, 15～30 fps
3.2M pixels, 1/2” CMOS, 2048×1536, USB 2.0, 15～30 fps
Head
Seidentopf binocular head , inclinded 30°, 360° rotatable,
interpupillary distance 50-75mm
Eyepiece
WF10X/20mm
Objective
Infinity EPLAN 4X/0.10
Infinity EPLAN 10X/0.25
Infinity EPLAN 40X/0.65(s)
Infinity EPLAN 100X/1.25(s,o)
Nosepiece
Quadruple Revolving Nosepiece
Condenser
Abbe N.A.1.25 with Iris diagram
Focusing
Coaxial coarse and fine focusing knob
Stage
Mechanical Stage 145 x140 mm, with
imported triangle track, moving range 76x52mm
Filter
Blue, Built-in
Light Source
6V20W halogen lamp with brightness control (85V-265V)
Software
Digital Image Analysis Software, for Windows2000 / XP / Vista
